Polyester Balls Double Filling Station Machine

Payment Type: L/C,T/T
Incoterm: FOB,CIF
Min. Order: 1 Set/Sets
Delivery Time: 15 Days

Basic Info


Model No.: 246B

Certification: CE, ISO

Type: Garment

Automatic Grade: Automatic

Condition: New

Function: Stuffing Clothes

Driven Type: Pneumatic

After-sales Service: Local Agent And Our Engineers


Additional Info


Packaging: Plywood box

Brand: BEALEAD

Transportation: Ocean,Air

Place of Origin: CHINA

Supply Ability: 200 SETS/MONTH

Certificate: CE/ISO 9001

Port: Shanghai


Product Description

The automatic down filling machine is our high performance down filling machine as well as fiber filling machine, developed to match Polyester balls filling material as well as Down fillings;

Very fast & Accurate down garment filling machine, has down returning system function.

Details:

Brand: Bealead

Model: 246B

Composed by: 1 feeding unit and 2 Weighing Units/ Filling Station

Filling Pipes: 2

Scales by filling pipe: 4

Fillings by hour: 1800 ( Polyester Balls)/ 1400 ( Down)

Application: Apparel, Commodity, Textiles

Material Application: 50%- 90% down

Weight: 1000kg

Filling Storage: 10kg

Weighing Range: 0.2g- 20g

Accuracy: 0.01g

Feeding Unit Size: 2.4* 0.9* 2m

Weighing Unit Size: 1.6* 0.5* 0.9m

Overall Size: 2.4* 4.2* 2m

Min. Site Area: 4m* 5m

Main Specification

Voltage
380V
Air Tank ≥1m³
Air Pressure 0.6- 0.8MPa
Air Compressor Power 11KW
Min. Air Pressure 0.5MPa
Air Compressor Exhaust
≥1.6m³/min
Max. Power 3.5KW
Air Monitoring System
PPR Pipe 1.5 inch
Down Returning System
Pipe Distance ≤20m
Humidity Control System      -


Our Factory      Automatic Machinery company

Exhibitions

Down Filling Machine Exhibition


CE Certificate

Filling Machine CE
